Black High Thermal Shock Resistance Customizable Silicon Nitride Ceramic for Non-Standard Structural Parts

Name: Black High Thermal Shock Resistance Customizable Silicon Nitride Ceramic for NonStandard Structural Parts
Brand: KEGU
Price: 200 USD

Wholesale Black High Thermal Shock Resistance Customizable Silicon Nitride Ceramic for Non-Standard Structural Parts from china suppliers

Brand Name : KEGU

Place of Origin : China

Price : 200-500 yuan/kg

Payment Terms : L/C,D/A,D/P,T/T,Western Union,MoneyGram

Supply Ability : 2,000 pcs/month

Packaging Details : Strong wooden box for Global shipping

Model Number : Customizable

Material : Silicon Nitride

Composition:SiC : ＞85%

Color : Black

Density : 3.20-3.26g/cm3

Max. Service Temp : 1450℃

Flexural Strength : 250MPa

Sample : Customizable

Chemical Stability : High

Apparent Porosity : 0-0.1%

Elastic Modulus : 300-320GPa

Compression Strength : >1500MPa

Vickers Hardness(HV0.5) : 15-16GPa

Thermal Conductivity : 20-25W/(m.k)

Specific Resistivity : 10^14Ω·cm

Contact Now

Product Description

Advanced silicon nitride ceramic materials, specifically engineered for the aluminum industry, offer superior thermal and mechanical properties compared to conventional alternatives. Building on this innovation, products like the L-shaped high thermal conductivity submerged heating appliance are set to deliver revolutionary improvements in aluminum industrial equipment performance.

Custom structural components demanding exceptional thermal shock resistance represent a key growth area for silicon nitride ceramics. In high-temperature, highly corrosive, and high-wear applications, silicon nitride is increasingly replacing traditional materials such as cemented carbide, alumina, zirconia, and silicon carbide.

Black High Thermal Shock Resistance Customizable Silicon Nitride Ceramic for Non-Standard Structural Parts

Silicon Nitride Ceramics: Property Comparison Data

Category	Property	Unit	99% Al₂O₃	S-SiC	ZrO₂	Si₃N₄
Physical	Density	g/cm³	3.9	3.1	6.0	3.2
	Water Absorption	%	0	0.1	0	0.1
	Sintering Temperature	°C	1700	2200	1500	1800
Mechanical	Hardness (HV)	HV	1700	2200	1300	1400
	Flexural Strength	kgf/mm²	3500	4000	9000	7000
	Compressive Strength	kgf/mm²	30000	20000	20000	23000
Thermal	Max Working Temperature	°C	1500	1600	1300	1400
	Thermal Expansion Coefficient (0-1000°C)	/°C	8.0 × 10⁻⁶	4.1 × 10⁻⁶ (0-500°C)	9.5 × 10⁻⁶	2.0 × 10⁻⁶ (0-500°C)
				5.2 × 10⁻⁶ (500-1000°C)		4.0 × 10⁻⁶ (500-1000°C)
	Thermal Shock Resistance	ΔT (°C)	200	250	300	400-500
	Thermal Conductivity (25°C)	W/m·K	31	100	3	25
	Thermal Conductivity (300°C)	W/m·K	16	100	3	25
Electrical	Volume Resistivity (20°C)	Ω·cm	>10¹²	10⁶–10⁸	>10¹⁰	>10¹¹
	Volume Resistivity (100°C)	Ω·cm	10¹²–10¹³	–	–	>10¹¹
	Volume Resistivity (300°C)	Ω·cm	>10¹²	–	–	>10¹¹
	Dielectric Breakdown Strength	kV/mm	18	Semiconductor	9	17.7
	Dielectric Constant (1 MHz)	ε	10	–	29	7
	Dielectric Loss Tangent	tan δ	0.4 × 10⁻³	–	–	–

Key Advantages of Silicon Nitride (Si₃N₄):

Excellent Thermal Shock Resistance (ΔT 400–500°C)
High Mechanical Strength & Toughness
Good Thermal Conductivity with low thermal expansion
Superior Wear & Corrosion Resistance
High-Temperature Stability up to 1400°C
Electrical Insulation Properties

Applications: Ideal for custom structural components in metallurgy, automotive, aerospace, energy, and industrial wear parts requiring reliability under extreme conditions.
